Mitutoyo 80x M Plan APO UV Objective - 378-839-5
Mitutoyo 80x M Plan APO UV Objective - 378-839-5

Mitutoyo 80x M Plan APO UV Objective - 378-839-5

Available: In Stock
Wishlist
  • Product SKU: 378-839-5
$21,330.00 $23,700.00
Request Quote

Mitutoyo 80x M Plan APO UV Objective - 378-839-5. This long working distance objective is ideal for use in visible (550nm) and the ultraviolet (266nm) regions of the spectrum.

Specifications
Type: Infinity Corrected Brightfield
Wavelength: Visible & UV
Magnification: 80x
N.A.: 0.55
Working Distance: 10mm
Wavelength Range: 266nm and 550nm
Focal Length UV Radiation: 2.5mm
Focal Length Visible Radiation: 2.9mm
Resolving Power: 0.5µm
Focal Depth:
0.9µm
Field of View with Ø24 Eyepiece Ø0.3
Real Field of View with 1/2" Chip Camera 0.05 x 0.08
Thread Size: M26
Part Number: 378-839-5

Mitutoyo 80x M Plan APO UV Objective - 378-839-5. This long working distance objective is ideal for use in visible (550nm) and the ultraviolet (266nm) regions of the spectrum.

Specifications
Type: Infinity Corrected Brightfield
Wavelength: Visible & UV
Magnification: 80x
N.A.: 0.55
Working Distance: 10mm
Wavelength Range: 266nm and 550nm
Focal Length UV Radiation: 2.5mm
Focal Length Visible Radiation: 2.9mm
Resolving Power: 0.5µm
Focal Depth:
0.9µm
Field of View with Ø24 Eyepiece Ø0.3
Real Field of View with 1/2" Chip Camera 0.05 x 0.08
Thread Size: M26
Part Number: 378-839-5
