Mitutoyo 80x M Plan APO SL Objective - 378-812-3
Mitutoyo 80x M Plan APO SL Objective - 378-812-3

Mitutoyo 80x M Plan APO SL Objective - 378-812-3

  • SKU: 378-812-3
$3,940.00
Request Quote

Mitutoyo 80x M Plan Apochromatic Super Long Working Distance Objective -378-812-3. The apochromatic optical design provides a flat, chromatic-aberration-free image for true-colour viewing, making this objective an ideal choice for metallurgical applications.

Specifications
Type: Infinity Corrected Brightfield
Wavelength: Visible
Magnification: 80x
N.A.: 0.42
Working Distance: 20.5mm
Focal Length: 4mm
Resolving Power: 0.7µm
Focal Depth:
1.6µm
Field of View with Ø24 Eyepiece Ø0.48
Real Field of View with 1/2" Chip Camera 0.10 x 0.13
Thread Size: M26
Part Number: 378-812-3
