Mitutoyo 50x M Plan APO SL Objective - 378-811-3

Recently viewed

Mitutoyo 50x M Plan APO SL Objective - 378-811-3
Mitutoyo 50x M Plan APO SL Objective - 378-811-3

Mitutoyo 50x M Plan APO SL Objective - 378-811-3

  • SKU: 378-811-3
$3,400.00
Request Quote
  • Order within

Mitutoyo 50x M Plan Apochromatic Super Long Working Distance Objective -378-811-3. The apochromatic optical design provides a flat, chromatic-aberration-free image for true-color viewing, making these Mitutoyo microscope objectives an ideal choice for metallurgical applications.



Replaced with 378-811-15

Specifications
Type: Infinity Corrected Brightfield
Wavelength: Visible
Magnification: 50x
N.A.: 0.42
Working Distance: 20.5mm
Focal Length: 4mm
Resolving Power: 0.7µm
Focal Depth:
1.6µm
Field of View with Ø24 Eyepiece Ø0.48
Real Field of View with 1/2" Chip Camera 0.10 x 0.13
Thread Size: M26
Part Number: 378-811-3

Mitutoyo 50x M Plan Apochromatic Super Long Working Distance Objective -378-811-3. The apochromatic optical design provides a flat, chromatic-aberration-free image for true-color viewing, making these Mitutoyo microscope objectives an ideal choice for metallurgical applications.



Replaced with 378-811-15

Specifications
Type: Infinity Corrected Brightfield
Wavelength: Visible
Magnification: 50x
N.A.: 0.42
Working Distance: 20.5mm
Focal Length: 4mm
Resolving Power: 0.7µm
Focal Depth:
1.6µm
Field of View with Ø24 Eyepiece Ø0.48
Real Field of View with 1/2" Chip Camera 0.10 x 0.13
Thread Size: M26
Part Number: 378-811-3
