Mitutoyo 50x M Plan APO Objective - 378-805-3
Mitutoyo 50x M Plan APO Objective - 378-805-3
- SKU: 378-805-3
$2,760.00
Mitutoyo 50x M Plan Apochromatic Objective -378-805-3. The apochromatic optical design provides a flat, chromatic-aberration-free image for true-colour viewing, making this objective an ideal choice for metallurgical applications.
Specifications | |
---|---|
Type: | Infinity Corrected Brightfield |
Wavelength: | Visible |
Magnification: | 50x |
N.A.: | 0.55 |
Working Distance: | 13.0mm |
Focal Length: | 4mm |
Resolving Power: | 0.5µm |
Focal Depth: |
0.9µm |
Field of View with Ø24 Eyepiece | Ø0.48 |
Real Field of View with 1/2" Chip Camera | 0.10 x 0.13 |
Thread Size: | M26 |
Part Number: | 378-805-3 |
