Mitutoyo 50x LCD Plan APO NIR Objective - 378-829-5
Mitutoyo 50x LCD Plan APO NIR Objective - 378-829-5
- SKU: 378-829-5
$6,010.00
Mitutoyo 50x LCD Plan APO NIR Objective - 378-829-5. This objective is suitable for laser applications and the long working distance allows for observation through an LCD cover-glass 0.7mm thick.
Specifications | |
---|---|
Type: | Infinity Corrected Brightfield |
Wavelength: | Visible & NIR |
Magnification: | 50x |
Glass Thickness: | .07mm |
N.A.: | 0.42 |
Working Distance: | 17.26mm |
Wavelength Range: | 480nm to 1800nm |
Focal Length: | 3.9 |
Resolving Power: | 0.7µm |
Focal Depth: |
1.6µm |
Field of View with Ø24 Eyepiece | Ø0.48 |
Real Field of View with 1/2" Chip Camera | 0.10 x 0.13 |
Thread Size: | M26 |
Part Number: | 378-829-5 |
