Mitutoyo 200x M Plan APO SL Objective - 378-816-3
Mitutoyo 200x M Plan APO SL Objective - 378-816-3

Mitutoyo 200x M Plan APO SL Objective - 378-816-3

  • SKU: 378-816-3
$10,080.00 $11,200.00
Request Quote

Mitutoyo 200x M Plan Apochromatic Super Long Working Distance Objective -378-816-3. The apochromatic optical design provides a flat, chromatic-aberration-free image for true-colour viewing, making this objective an ideal choice for metallurgical applications.

Specifications
Type: Infinity Corrected Brightfield
Wavelength: Visible
Magnification: 200x
N.A.: 0.62
Working Distance: 13.0mm
Focal Length: 1mm
Resolving Power: 0.4µm
Focal Depth:
0.7µm
Field of View with Ø24 Eyepiece Ø0.12
Real Field of View with 1/2" Chip Camera 0.025 x 0.03
Thread Size: M26
Part Number: 378-816-3
