Mitutoyo 1x M Plan APO Brightfield Objective - 378-800-3
Mitutoyo 1x M Plan APO Brightfield Objective - 378-800-3

Mitutoyo 1x M Plan APO Brightfield Objective - 378-800-3

  • SKU: 378-800-3
$2,295.00 $2,550.00
Request Quote
  • Order within

Mitutoyo 1x M Plan Apochromat Brightfield Objective with built-in 1/4 Wave retardation plate for glare reduction. This product had a slight design change and is now part number 378-800-12.

Specifications
Type: Infinity Corrected Brightfield
Wavelength: Visible
Magnification: 1x
N.A.: 0.025
Working Distance: 11.0mm
Resolving Power: 11.0µm
Focal Depth:
440µm
Field of View with Ø24 Eyepiece Ø24
Real Field of View with 1/2" Chip Camera 4.8 x 6.4
Thread Size: M26
Part Number: 378-800-3

Mitutoyo 1x M Plan Apochromat Brightfield Objective with built-in 1/4 Wave retardation plate for glare reduction. This product had a slight design change and is now part number 378-800-12.

Specifications
Type: Infinity Corrected Brightfield
Wavelength: Visible
Magnification: 1x
N.A.: 0.025
Working Distance: 11.0mm
Resolving Power: 11.0µm
Focal Depth:
440µm
Field of View with Ø24 Eyepiece Ø24
Real Field of View with 1/2" Chip Camera 4.8 x 6.4
Thread Size: M26
Part Number: 378-800-3
