Mitutoyo 100x M Plan APO SL Objective - 378-813-3
Mitutoyo 100x M Plan APO SL Objective - 378-813-3
- SKU: 378-813-3
$4,930.00
Mitutoyo 100x M Plan Apochromatic Super Long Working Distance Objective -378-813-3. The apochromatic optical design provides a flat, chromatic-aberration-free image for true-colour viewing, making this objective an ideal choice for metallurgical applications.
Specifications | |
---|---|
Type: | Infinity Corrected Brightfield |
Wavelength: | Visible |
Magnification: | 100x |
N.A.: | 0.55 |
Working Distance: | 13.0mm |
Focal Length: | 2mm |
Resolving Power: | 0.5µm |
Focal Depth: |
0.9µm |
Field of View with Ø24 Eyepiece | Ø0.24 |
Real Field of View with 1/2" Chip Camera | 0.05 x 0.06 |
Thread Size: | M26 |
Part Number: | 378-813-3 |
Mitutoyo 100x M Plan Apochromatic Super Long Working Distance Objective -378-813-3. The apochromatic optical design provides a flat, chromatic-aberration-free image for true-colour viewing, making this objective an ideal choice for metallurgical applications.
Specifications | |
---|---|
Type: | Infinity Corrected Brightfield |
Wavelength: | Visible |
Magnification: | 100x |
N.A.: | 0.55 |
Working Distance: | 13.0mm |
Focal Length: | 2mm |
Resolving Power: | 0.5µm |
Focal Depth: |
0.9µm |
Field of View with Ø24 Eyepiece | Ø0.24 |
Real Field of View with 1/2" Chip Camera | 0.05 x 0.06 |
Thread Size: | M26 |
Part Number: | 378-813-3 |
