Mitutoyo 100x M Plan APO NIR High Resolution Objective - 378-864-5
Mitutoyo 100x M Plan APO NIR High Resolution Objective - 378-864-5

Mitutoyo 100x M Plan APO NIR High Resolution Objective - 378-864-5

Available: In Stock
Wishlist
  • Product SKU: 378-864-5
$9,720.00 $10,800.00
Request Quote

Mitutoyo 100x M Plan APO NIR High Resolution Objective - 378-864-5. This objective is suitable for laser applications and provides long working distances between the lens and working surface. The high numerical aperture provides high resolution.

Specifications
Type: Infinity Corrected Brightfield
Wavelength: Visible & NIR
Magnification: 100x
N.A.: 0.70
Working Distance: 10mm
Wavelength Range: 480nm to 1800nm
Focal Length: 2mm
Resolving Power: 0.4µm
Focal Depth:
0.6µm
Field of View with Ø24 Eyepiece Ø0.24
Real Field of View with 1/2" Chip Camera 0.05 x 0.06
Thread Size: M26
Part Number: 378-864-5
