Unitron Z6 Zoom Stereo Microscope Series on Plain Focusing Stand

Recently viewed

Unitron Z6 Zoom Stereo Microscope Series on Plain Focusing Stand
Unitron Z6 Zoom Stereo Microscope Series on Plain Focusing Stand
Unitron Z6 Zoom Stereo Microscope Series on Plain Focusing Stand

Unitron Z6 Zoom Stereo Microscope Series on Plain Focusing Stand

  • SKU: 11150-131-13-05-05A
$2,324.00 $2,641.00
  • Binocular or Ergo Tilting Binocular Head
  • 8x - 50x Zoom w/ Click Stops
  • Optional Objectives
  • Plain Focusing Stand
  • 5 Year Mechanical & Electrical Warranty
Head Type
Quote Request

The Unitron Z6 stereo microscope is a high resoultion common main objective style microscope with an 8x - 50x zoom range. It comes with 10x eyepieces that provide a large 24mm field of view. It has 7 click stops throughout the zoom which can be turned on or off as needed. You can choose between a binocular head or an ergonomic tilting binocular head for added ergonomics. This microscope is a modular microscope and can be configured with various accessories to meet your needs. This includes a 1x plan achromat objective which gives this system 78mm working distance. Optional 0.3x, 0.5x, and 2.0x objectives are available to increase or decrease the working distance. This package includes the plain focusing stand. You can add a ring light or dual gooseneck illuminator as needed.

This high quality stereo microscope is ideal for inspection, quality control, failure analysis, and life science applications.



Specifications
Head: Binocular viewing head, inclined at 20° OR Ergo tilting (0° - 35°) binocular viewing head
Eyepieces: WF10x eyepieces with built-in diopter adjustment (paired), 24mm field of view - accepts 26.5mm reticle.
Magnification: 8x - 50x Zoom (7 Click Stops, Can Turn On/Off)
Objectives:

1.0x plan achromat objective, N.A. 0.09, working distance 78mm



Working Distance: 78mm (With 1x Objective)
Stand: Plain focusing stand with ø76mm pod holder, black and white contrast plate
Accessories: Dust cover, eyeguards and instruction manual.
Warranty: 1 year electrical & 5 year mechanical

The Unitron Z6 stereo microscope is a high resoultion common main objective style microscope with an 8x - 50x zoom range. It comes with 10x eyepieces that provide a large 24mm field of view. It has 7 click stops throughout the zoom which can be turned on or off as needed. You can choose between a binocular head or an ergonomic tilting binocular head for added ergonomics. This microscope is a modular microscope and can be configured with various accessories to meet your needs. This includes a 1x plan achromat objective which gives this system 78mm working distance. Optional 0.3x, 0.5x, and 2.0x objectives are available to increase or decrease the working distance. This package includes the plain focusing stand. You can add a ring light or dual gooseneck illuminator as needed.

This high quality stereo microscope is ideal for inspection, quality control, failure analysis, and life science applications.



Specifications
Head: Binocular viewing head, inclined at 20° OR Ergo tilting (0° - 35°) binocular viewing head
Eyepieces: WF10x eyepieces with built-in diopter adjustment (paired), 24mm field of view - accepts 26.5mm reticle.
Magnification: 8x - 50x Zoom (7 Click Stops, Can Turn On/Off)
Objectives:

1.0x plan achromat objective, N.A. 0.09, working distance 78mm



Working Distance: 78mm (With 1x Objective)
Stand: Plain focusing stand with ø76mm pod holder, black and white contrast plate
Accessories: Dust cover, eyeguards and instruction manual.
Warranty: 1 year electrical & 5 year mechanical

Please Contact Us for all additional parts and accessories
