Optika B-290 LED Fluorescence Microscope
Optika B-290 LED Fluorescence Microscope
Optika B-290 LED Fluorescence Microscope

Optika B-290 LED Fluorescence Microscope

  • SKU: B-292LD1.50
$2,016.00
  • Binocular or Trinocular
  • LED Fluorescence Illuminator
  • 10x, 20x, 40x, 50x OR 10x, 20x, 40x, 100x Objectives
  • Rackless Mechanical Stage
  • 10 Year Mechanical & 2 Year Electrical Warranty
Head
Objectives
Request Quote

The Optika B-290 fluorescence microscope features LED fluorescence illumination so you no longer have to worry about bulb changes, warm-up, cool-down, or centering your bulb! The Epi fluorescence attachment has 2 fluorescence positions and a brightfield position, with 1 filter set included with the cost of this microscope, see options below. This microscope is offered with a binocular or trinocular viewing head. It comes standard with a pair of 10x W.F. eyepieces which provide a 20mm field of view. You can choose between the following objective choices - 10x, 20x, 40x, and 50x or 10x, 20x, 40x, 100x dry. The XY mechanical stage is rackless which provides smooth and precise movements. The 1.25 N.A. condenser is coded for each objective and is focuasble, centerable, and contains an iris diaphragm. The X-LED3 brightfield illuminator allows for high intensity output with low power consumption.



Specifications
Head: Binocular (B292LD1 & B292LD1.50) or Trinocular (B293LD1 & B293LD1.5), 360° rotating and 30° inclined. Interpupillary distance from 48 to 75 mm; dioptric adjustment on left eyepiece.
Epi Fluorescence:

Slider with 3 positions (2 fluorescence, 1 brightfield), with 1 included filterset: Fluorescence B: EX 460-490, DM 505, EM 515LP: Acridine Yellow, Acridine Orange, Auramine, DiO, DTAF,
FITC, GFP, YFP, etc.

Extra efficiency LED, with light intensity control. Peak wavelength: 465 nm, Power: 3.6W

Eyepieces: WF10x/20 mm, high eye-point and secured by a screw.
Nosepiece: Quadruple revolving nosepiece, rotation on ball bearings.
Objectives:



B-292LD1 & B293LD1 - IOS N-Plan 10x/0.25, 20x/0.4040x/0.65, 100x/0.80 (Dry)

B-292LD1.50 & B293LD1.50 - IOS N-Plan 10x/0.2520x/0.4040x/0.65 , 50x/0.75 (No Cover - IOS W-Plan MET)

Stage: Double layer rackless mechanical sliding stage, 150×139 mm, 75×33 mm X-Y movement range. Vernier scale on the two axes, accuracy: 0.1 mm.
Condenser: Abbe N.A. 1.25, with objective-coded iris diaphragm, focusable and centerable.
Focusing: Coaxial coarse and fine focusing mechanism with limit stop to prevent the contact between objective and specimen.
Illumination:

 X-LED3 with white 3.6 W LED (6,300 K) and light intensity control.
Multi-plug 100-240Vac/6Vdc external power supply.

Warranty: 10 Year Mechanical & 2 Year Electrical
