Olympus GX51 Inverted Metallurgical Microscope

Recently viewed

Olympus GX51 Inverted Metallurgical Microscope
Olympus GX51 Inverted Metallurgical Microscope
Olympus GX51 Inverted Metallurgical Microscope

Olympus GX51 Inverted Metallurgical Microscope

  • SKU: GX51
$18,000.00
Request Quote

The Olympus GX51 inverted metallurgical microscope is a a solid high quality and reliable microscope. This inverted microscope comes with a binocular viewing head with 10x eyepieces. The front photo port allows for adding a camera. The grain size reticle can be inserted with the scale slider provided, and there is room for adding two more reticles to the slider. The large XY mechanical stage has a flexible right handed stage control for added ergonomics. The Olympus GX-AN360 and GX-PO give this microscope polarizing capabilities to help reduce glare and reflection and the GX-FSL contains three ND filters. The 5 position nosepiece has the following objective lenses - MPlanFL N 1.25x, MPlanFL N 2.5x, MPlanFL N 10x BD, MPlan FL N 20x, and UMPlanFL 40x. This microscope is capable of brightfield and darkfield and can be fully customized for your needs. This refurbished microscope comes fully serviced with a warranty!



Olympus GX51 Specifications
Viewing Head: Binocular Head
Eyepieces: 10x/22mm eyepieces
Scale: GX-SLM Scale Slider w/ Grain Size Reticle
Polarizer & Analyzer: GX-PO Polarizer & GX-AN360 Rotating Analyzer
Stage: GX-SFR Large Stage w/ Flexible Handle
Nosepiece: 5 Position
Objectives: MPlanFL N 1.25x, MPlanFL N 2.5x, MPlanFL N 10x BD, MPlan FL N 20x, and UMPlanFL 40x
Focusing: Coarse & Fine Focus
Lamphouse: 100 Watt Lamphouse
Misc: GX-FSL w/ neutral density filters
Warranty: 1 Year
