Olympus CK40 Illuminator LED Upgrade Kit

Recently viewed

Olympus CK40 Illuminator LED Upgrade Kit
Olympus CK40 Illuminator LED Upgrade Kit

Olympus CK40 Illuminator LED Upgrade Kit

$495.00
Request Quote

This LED illuminator is designed specifically for the Olympus CK40 microscope, and replaces all existing electronics. If you have a CK40 with failed circuit board, rheostat, or socket this is the perfect solution It provides brighter illumination while being more energy  efficient. You can install this yourself, or we can install this into your microscope for an additional cost.

  • Custom-designed to fit the form factor of the Olympus CK40.
  • The CK40 OEM lamp house has two pins on either sides of the bulb (similar to BX40). The pin spacing (center to center) is 37mm (1.457 in) which is the spacing for the BX40/41 and most others of that type including CKX41. While the BH-2, CK2 and SZX-ILLK use the same pins but has a spacing of 36mm (1.42 in).
  • Remote adjustment on an existing control on the microscope is standard. Brightness control potentiometer on the new illuminator available on request.
  • Easy installation and most tools provided.
  • All illuminator systems are backed by our 3-year warranty.
  • Illuminator Dimensions: 2.45 x 2.45 x 2.36 inch
  • Power Requirements: 5 to 24V/3.5W
  • Brightness: 410 lm
  • LED Expected Lifetime: 80% of original brightness at 88,500 hours
  • Material: Anodized 6061 T6 Aluminum

This LED illuminator is designed specifically for the Olympus CK40 microscope, and replaces all existing electronics. If you have a CK40 with failed circuit board, rheostat, or socket this is the perfect solution It provides brighter illumination while being more energy  efficient. You can install this yourself, or we can install this into your microscope for an additional cost.

  • Custom-designed to fit the form factor of the Olympus CK40.
  • The CK40 OEM lamp house has two pins on either sides of the bulb (similar to BX40). The pin spacing (center to center) is 37mm (1.457 in) which is the spacing for the BX40/41 and most others of that type including CKX41. While the BH-2, CK2 and SZX-ILLK use the same pins but has a spacing of 36mm (1.42 in).
  • Remote adjustment on an existing control on the microscope is standard. Brightness control potentiometer on the new illuminator available on request.
  • Easy installation and most tools provided.
  • All illuminator systems are backed by our 3-year warranty.
  • Illuminator Dimensions: 2.45 x 2.45 x 2.36 inch
  • Power Requirements: 5 to 24V/3.5W
  • Brightness: 410 lm
  • LED Expected Lifetime: 80% of original brightness at 88,500 hours
  • Material: Anodized 6061 T6 Aluminum
