Moticam Pro 285D Microscope Camera
$4,400.00
$4,896.00
For many years, our unique "From Box to Pics" approach has given a wide range of markets unprecedented access to affordable Digital Microscopy. Our new Moticam Pro series take this approach to the CCD scientific level by offering as much as possible in a single box making this series our most powerful and flexible camera series yet.
- C/CS mount scientific camera
- ICX205AL 1/2” CCD Monochrome
- 1.4MP - 1360x1024 pixels with USB2.0 output
- On-board 4-frame image buffer
- TTL port
- Pixel size 4,65 x 4,65
- Moticam Pro software CD (Motic Images Plus 2.0, TWAIN, SDK)
- Motic USB2 driver
- Motic Images Advanced 3.2 with dongle and calibration slide
| Sensor | |
| Sensor Type | CCD |
| Sensor Size | 1/2 Inch |
| Sensor Details | Sony ICX205AL |
| Color/Monochrome | Monochrome |
| Pixel Pitch | 4.65 µm |
| Scan Mode | Interleave |
| Shutter | Electronic, Global Shutter, Supports External Trigger |
| Camera | |
| Camera Mount | C-Mount |
| Resolution | 1.4 Megapixel, 1360x1024 pixels |
| Camera Interface | USB 2.0 |
| White Balance | Area-of-Interest, Automatic, Manual, Spot |
| Black Balance | Manual, Spot |
| Software Included | Motic Images Advanced 3.2, Includes SDK |
| Driver API Compatibility | DirectX, TWAIN |
| Camera Power Source | USB Powered |
| Exposure Control | Area-of-Interest, Automatic, Manual, Spot, Vignetting Correction |
| Supported Operating Systems | Macintosh OSX 10.4+, Windows XP, Windows Vista, Windows 7 |
| System Requirements | 2GB RAM Recommended, 2Ghz+ CPU Recommended, At least P4-class CPU, Intel Mac Required for OSX Support, USB 2.0 High Speed Port |
For many years, our unique "From Box to Pics" approach has given a wide range of markets unprecedented access to affordable Digital Microscopy. Our new Moticam Pro series take this approach to the CCD scientific level by offering as much as possible in a single box making this series our most powerful and flexible camera series yet.
- C/CS mount scientific camera
- ICX205AL 1/2” CCD Monochrome
- 1.4MP - 1360x1024 pixels with USB2.0 output
- On-board 4-frame image buffer
- TTL port
- Pixel size 4,65 x 4,65
- Moticam Pro software CD (Motic Images Plus 2.0, TWAIN, SDK)
- Motic USB2 driver
- Motic Images Advanced 3.2 with dongle and calibration slide
| Sensor | |
| Sensor Type | CCD |
| Sensor Size | 1/2 Inch |
| Sensor Details | Sony ICX205AL |
| Color/Monochrome | Monochrome |
| Pixel Pitch | 4.65 µm |
| Scan Mode | Interleave |
| Shutter | Electronic, Global Shutter, Supports External Trigger |
| Camera | |
| Camera Mount | C-Mount |
| Resolution | 1.4 Megapixel, 1360x1024 pixels |
| Camera Interface | USB 2.0 |
| White Balance | Area-of-Interest, Automatic, Manual, Spot |
| Black Balance | Manual, Spot |
| Software Included | Motic Images Advanced 3.2, Includes SDK |
| Driver API Compatibility | DirectX, TWAIN |
| Camera Power Source | USB Powered |
| Exposure Control | Area-of-Interest, Automatic, Manual, Spot, Vignetting Correction |
| Supported Operating Systems | Macintosh OSX 10.4+, Windows XP, Windows Vista, Windows 7 |
| System Requirements | 2GB RAM Recommended, 2Ghz+ CPU Recommended, At least P4-class CPU, Intel Mac Required for OSX Support, USB 2.0 High Speed Port |
