Moticam Pro 282A Microscope Camera

Motic Cameras

$3,800.00  $4,264.00

Request Quote

For many years, our unique "From Box to Pics" approach has given a wide range of markets unprecedented access to affordable Digital Microscopy. Our new Moticam Pro series take this approach to the CCD scientific level by offering as much as possible in a single box making this series our most powerful and flexible camera series yet.

  • C/CS mount scientific camera
  • ICX205AK 1/2” CCD Color Peltier Cooled
  • 1.4MP - 1360x1024 pixels with USB2.0 output
  • On-board 4-frame image buffer
  • TTL port
  • Pixel size 4,65 x 4,65
  • Moticam Pro software CD (Motic Images Plus 2.0, TWAIN, SDK)
  • Motic USB2 driver
  • Motic Images Advanced 3.2 with dongle and calibration slide
    Sensor
    Sensor Type CCD
    Sensor Size 2/3 Inch
    Sensor Details Sony ICX282AQ
    Color/Monochrome Color
    Pixel Pitch 3.40 µm
    Scan Mode Interleave
    Peltier Cooling Yes
    Cooling System Peltier Cooling provides approximately 10°C temperature below ambient
    Shutter Electronic, Global Shutter, Supports External Trigger
    Camera
    Camera Mount C-Mount
    Resolution 5 Megapixel, 2580x1944 pixels
    Camera Interface USB 2.0
    White Balance Area-of-Interest, Automatic, Manual, Spot
    Black Balance Manual, Spot
    Software Included Motic Images Advanced 3.2, Includes SDK
    Driver API Compatibility DirectX, TWAIN
    Camera Power Source External Power Supply
    Exposure Control Area-of-Interest, Automatic, Manual, Spot, Vignetting Correction
    Supported Operating Systems Macintosh OSX 10.4+, Windows XP, Windows Vista, Windows 7
    System Requirements 2GB RAM Recommended, 2Ghz+ CPU Recommended, At least P4-class CPU, Intel Mac Required for OSX Support, USB 2.0 High Speed Port
