Moticam Pro 205C Microscope Camera

Moticam Pro 205C Microscope Camera

$2,400.00 $2,678.00
Request Quote
For many years, our unique "From Box to Pics" approach has given a wide range of markets unprecedented access to affordable Digital Microscopy. Our new Moticam Pro series take this approach to the CCD scientific level by offering as much as possible in a single box making this series our most powerful and flexible camera series yet.
  • C/CS mount scientific camera
  • ICX205AL 1/2” CCD Monochrome
  • 1.4MP - 1360x1024 pixels with USB2.0 output
  • On-board 4-frame image buffer
  • TTL port
  • Pixel size 4,65 x 4,65
  • Moticam Pro software CD (Motic Images Plus 2.0, TWAIN, SDK)
  • Motic USB2 driver
  • Motic Images Advanced 3.2 with dongle and calibration slide
Sensor
Sensor Type CCD
Sensor Size 1/2 Inch
Sensor Details Sony ICX205AL
Color/Monochrome Monochrome
Pixel Pitch 4.65 µm
Scan Mode Interleave
Shutter Electronic, Global Shutter, Supports External Trigger
Camera
Camera Mount C-Mount
Resolution 1.4 Megapixel, 1360x1024 pixels
Camera Interface USB 2.0
White Balance Area-of-Interest, Automatic, Manual, Spot
Black Balance Manual, Spot
Software Included Motic Images Advanced 3.2, Includes SDK
Driver API Compatibility DirectX, TWAIN
Camera Power Source USB Powered
Exposure Control Area-of-Interest, Automatic, Manual, Spot, Vignetting Correction
Supported Operating Systems Macintosh OSX 10.4+, Windows XP, Windows Vista, Windows 7
System Requirements 2GB RAM Recommended, 2Ghz+ CPU Recommended, At least P4-class CPU, Intel Mac Required for OSX Support, USB 2.0 High Speed Port
