Mitutoyo 7.5x M Plan APO Objective - 378-807-3
Mitutoyo 7.5x M Plan APO Objective - 378-807-3

Mitutoyo 7.5x M Plan APO Objective - 378-807-3

  • SKU: 378-807-3
$1,161.00 $1,290.00
Request Quote

Mmitutoyo 7.5x M Plan Apochromatic Objective - 378-807-3. The apochromatic optical design provides a flat, chromatic-aberration-free image for true-colour viewing, making this objective an ideal choice for metallurgical applications.



Specifications
Type: Infinity Corrected Brightfield
Wavelength: Visible
Magnification: 7.5x
N.A.: 0.21
Working Distance: 35.0mm
Focal Length: 26.67mm
Resolving Power: 1.3µm
Focal Depth:
6.2µm
Field of View with Ø24 Eyepiece Ø3.2
Real Field of View with 1/2" Chip Camera 0.64 x 0.85
Thread Size: M26
Part Number: 378-807-3
