Mitutoyo 2x M Plan APO Objective - 378-801-6

Recently viewed

Mitutoyo 2x M Plan APO Objective - 378-801-6
Mitutoyo 2x M Plan APO Objective - 378-801-6

Mitutoyo 2x M Plan APO Objective - 378-801-6

  • SKU: 378-801-6
$937.00
Request Quote

Mitutoyo 2x M Plan Apochromatic Objective - 378-801-6. The apochromatic optical design provides a flat, chromatic-aberration-free image for true-colour viewing, making this objective an ideal choice for metallurgical applications.

Specifications
Type: Infinity Corrected Brightfield
Wavelength: Visible
Magnification: 2x
N.A.: 0.055
Working Distance: 34mm
Resolving Power: 5.0µm
Focal Depth:
91µm
Field of View with Ø24 Eyepiece Ø12
Real Field of View with 1/2" Chip Camera 2.4 x 3.2
Thread Size: M26
Part Number: 378-801-6
