Industrial Inspection Zoom Monocular Microscope with Double Arm Stand and 1080p HDMI Camera

Industrial Inspection Zoom Monocular Microscope with Double Arm Stand and 1080p HDMI Camera

|

SKU: H800-DAB-96S-HD1080

Regular price $2,210.99
Regular price $2,652.99 Sale price $2,210.99
Sale Sold out
Quote Request
Industrial Inspection Zoom Monocular Microscope with Double Arm Stand and 1080p HDMI Camera
Got Questions? Why Choose Us? View full details

Description

The H800 is an extremely high-detail monocular inspection microscope with a 0.7X to 5X zoom range. Mounted on a heavy-duty double-arm stand, this microscope is the ideal tool for inspection applications. The included LED ring-light offers even, cool illumination. The 1080p 60fps camera provides crystal-clear, stutter-free video for live monitoring and recording via the HDMI interface. Attach it directly to a monitor or television, and use the built-in software for turnkey video inspection. Attach it to a PC via its USB 2.0 interface, and use the included software to record still images and video up to 30fps.

Features:

  • 0.7X-5.0X zoom objective
  • C-mount lens
  • Long working distance
  • Sharp images over a super wide field view
  • Large Metal stand and framework
  •

    Specifications :

  • Zoom microscope objective: 0.7X-5.0X
  • Mount: 0.4X C-mount
  • Working distance: 4-1/8" (105mm)
  • Stand is 30" Overall Length
  • 20" Double Arms
  • 17" High Pillar
  • 10-1/4" x 8-1/4" x 2-0" Solid Cast Steel Base
  • Color: black
  •

    Camera Specifications:

  • Sensor: Sony IMX236 CMOS
  • Sensor Size: 1/2.8"
  • Preview and Capture Resolution: 3264x1840 (SD Card),  3264x1840, 1920x1080 (PC)
  • Video Resolution: 1920x1080
  • Live Frame Rate: 60fps @ 1920x1080 via HDMI, 30fps @ 1920x1080 via USB2.0 & SD Card Slot Recording
  • Recording Frame Rate: 30fps @ 1920x1080
  • Image Storage: SD Card Slot
  • Scan Mode: Progressive
  • Exposure Time: 0.001 sec ~ 10.0 sec
  • White Balance: Auto
  • Settings: Gain, Gamma, Saturation, Cotraction
  • Screen Built-in Software: Cloud 1.0
  • PC Software: ISCapture
  • Interfaces: USB2.0, HDMI
  • Compatibility: Windows XP/7/8 (32/64 bit)
  • Optical Port: Standard C-mount
  • Power Supply: DC 12V / 2A
  • Dimensions: 78mm x 70.8mm x 90.7mm
  •

    Built-in Software Features

  • - Captures Still Images & Records Video
  • - 1080p Video Recording (30 fps)
  • - Auto Exposure & Manual Exposure Setting Options
  • - Saturation, Brightness, Contrast, & Tint Options
  • - Auto White Balance Functionality
  • - 3D Noise Reduction
  • - ROI Magnification Functions (Image Flip, Rotation, ROI)
  • - Image Side by Side Comparison Functionality
  • - Built-in File Browser
  • - Lifetime software updates
  •

    Computer Software Features

  • - Compatible with Windows XP/Vista/7/8 (32 & 64 bit) & Mac OS X 10.6.8+
  • - Computer Requirements: CPU Equivalent to Intel Core2 2.8GHz or higher, Memory: 2GB or more, USB2.0 port
  • - Preview live images right on your computer
  • - Record images and video (30 fps record rate over USB2.0)
  • - Auto and manual control of exposure, gain, white balance, gamma, contrast, saturation, and more
  • - Lifetime software updates
  •

    Packing List :

  • One Monocular Zoom Microscope Head with 0.7-5.0X Objective and 0.4X C-Mount Lens
  • One Focusing Rack
  • One Double-arm Heavy-duty Stand
  • One Dust Cover
  • One 96-LED ring-light
  • One Control Unite for Light
  • One AC Adapter for Light
  • One 1080P Digital Camera
  • One USB Mouse
  • One HDMI Cable
  • One USB Cable
  • One Software CD
  • One AC Adapter for Camera
  •

    AmScope H800-DAB-96S-HD1080
