Industrial Inspection Zoom Monocular Microscope with 1920x1080p HDMI Camera & 11.5" HD Monitor

Recently viewed

Industrial Inspection Zoom Monocular Microscope with 1920x1080p HDMI Camera & 11.5" HD Monitor
Industrial Inspection Zoom Monocular Microscope with 1920x1080p HDMI Camera & 11.5" HD Monitor

Industrial Inspection Zoom Monocular Microscope with 1920x1080p HDMI Camera & 11.5" HD Monitor

  • SKU: H800-96S-HD1080A-HDM
$1,142.99 $2,285.99
Request Quote

This is a monocular inspection microscope with 0.7X-5.0X zoom objective and 0.4X C-mount lens. It offers large working distance, super widefield of view and crystal clear sharp images. It is ready to connect to a PC or TV camera. Included is our 1920x1080, 15fps via HDMI or USB2.0 digital camera kit with 11.5" monitor for live viewing and recording of your microscope image!

Features :

  • 0.7X-5.0X zoom objective
  • C-mount lens
  • Long working distance
  • Includes 1920x1080p HDMI/USB2.0 Digital Camera & 11.5" HDMI Monitor
  • Sharp images over a super wide field view
  • Large Metal stand and framework
  •

    Specifications :

  • Zoom microscope objective: 0.7X-5.0X
  • Mount: 0.4X C-mount for PC or TV camera connection
  • Working distance: 4-1/8" (105mm)
  • Field of view: 1/2"x11/16" (12.9mm X 17.1mm) to 5/64"x3/32" (1.8mm X 2.4mm)
  • Power input: 110-240V, 50-60HZ, auto switching
  • Metal stand dimension: 13"x10"
  • Pillar: 11" (280mm) long
  •

    Camera Specifications:

  • Sensor: Aptina MT9P031 CMOS
  • Sensor Size: 1/2.5 inch (10mm)
  • Pixel Size: 2.2µm
  • Preview Resolution: 1920 x 1080
  • Still Capture Resolution: 2592 x 1944
  • Video Capture Resolution: 1920 x 1080
  • Video Framerate: 15fps SD Card, 15fps USB, 15fps HDMI
  • Recording Media: SD Card (4G)
  • Exposure Time: 1/1000 - 10s
  • Exposure Modes: Automatic, Manual
  • Settings: Gain, Gamma, Saturation, Contrast
  • White Balance: Automatic
  • Interfaces: USB 2.0, HDMI
  • Built-in Software: Cloud v1.0
  • Software: ISCapture
  • Compatible Operating Systems: Win XP/7/8 (32/64bit)
  • Optical Port: Standard C-mount (aluminum)
  • Power Supply: DC 12V 2A
  • Operational Temperatures: 0 - 60°C
  • Storage Temperature: -20 - 70°C
  • Humidity Tolerance: 45% - 85%
  • Dimensions: 74.4mm x 67.2mm x 90.9mm
  • Weight: 1Kg
  •

    Built-in Software Features

  • - Captures Still Images & Records Video
  • - 1080p Video Recording (15 fps)
  • - Auto Exposure & Manual Exposure Setting Options
  • - Saturation, Brightness, Contrast, & Tint Options
  • - Auto White Balance Functionality
  • - 3D Noise Reduction
  • - ROI Magnification Functions (Image Flip, Rotation, ROI)
  • - Image Side by Side Comparison Functionality
  • - Built-in File Browser
  • - Lifetime software updates
  • Computer Software Features
  • - Compatible with Windows XP/Vista/7/8 (32 & 64 bit) & Mac OS X 10.6.8+
  • - Computer Requirements: CPU Equivalent to Intel Core2 2.8GHz or higher, Memory: 2GB or more, USB2.0 port
  • - Preview live images right on your computer
  • - Record images and video
  • - Auto and manual control of exposure, gain, white balance, gamma, contrast, saturation, and more
  • - Lifetime software updates
  •

    Packing List :

  • One Monocular Zoom Microscope Head with 0.7-5.0X Objective and 0.4X C-Mount Lens
  • One Focusing Rack
  • One Pillar Plate Stand
  • Dust Cover
  • 96-LED Ring Light
  • Camera Body
  • HDMI Cable
  • Power Supply
  • 11.5" 1920x1080 HD Monitor
  • Power Supply
  • Mounting Kit
  • Shipping Weight: 18 lbs
  • AmScope H800-96S-HD1080A-HDM
