Diagnostic Imaging Spot Xplorer 1.4 MP Monochrome Digital Microscope Camera

Diagnostic Imaging Spot Xplorer 1.4 MP Monochrome Digital Microscope Camera

Diagnostic Imaging Spot Xplorer Monochrome  Digital Microscope Camera - 1.4 Megapixels! Comes with power supply and cables!   The SPOT™ Xplorer Monochrome digital camera offers deep...

$1,250.00
Request Quote
Add to wishlist
Diagnostic Imaging Spot Xplorer Monochrome
Digital Microscope Camera - 1.4 Megapixels!
Comes with power supply and cables!

The SPOT™ Xplorer Monochrome digital camera offers deep cooling and high speed, optimizing sensitivity for low light scientific applications. 14-bit digitization with multiple readout speeds add flexibility for recording dynamic events. Its CCD sensor provides megapixel resolution and high quantum efficiency, especially in the near-IR portion of the spectrum. The primary applications for this camera include live cell GFP imaging, ion tracking, high content screening, immunofluorescence and 3D deconvolution.
  • Resolution               |    1.4 Mp
  • Sensor Type           |    Sony ICX285AL with cover glass Monochrome Progressive scan interline                                          CCD Shutter
  • Active Pixels           |    1360 x 1024
  • Pixel Size                |     6.45 μm x 6.45 μm
  • Optical Format        |     2/3"
  • Active Imager Size |     8.77mm (H) x 6.60mm (V)
  • Exposure Time       |     0.5ms – 1500sec
  • Anti-Blooming         |    100x minimum
  • Binning                     |    2 x 2, 3 x 3, 4 x 4, 8 x 8
  • Read Noise             |    4.5 e- @ 10 MHz; 5.5 e- @ 20MHz
  • A-D Converter         |    14-Bit @ 20 MHz DCS
  • Cooling                    |     -40° C regulated cooling via thermoelectric cooler with hermetically sealed,                                        fan cooled heat sink, -70° C maximum differential cooling from ambient
  • Lens Mount              |     C-Mount with adjustable back focus
  • Computer Interface |      PCI Express
  • Weight                      |     4.5 lbs (1.09 kg)
