AmScope Turret Phase Contrast Binocular Microscope 40X-1600X
![]()
![]()
![Accu-Scope 3000 LED Microscope - Microscope Central
- 2]()
![Accu-Scope 3000 Digital Microscope Package]()
A Phase Contrast and Bright Field Microscopy System
Perfect for Clinics, Vets, Doctors and Researchers
Quadruple, Reversed, Extra-Large Nosepiece with Wide, Knurled Grip for Easy Operation
30 Degree Inclined 360 Degree Swiveling Compensation-free Binocular Head
Large 3-D Double Layer Mechanical Stage with Stain Resistant Finish
Low Position Coaxial Stage Movement Control Knobs
Coaxial Coarse & Fine Focusing with CA Knob Tension Control
Fully Coated Optical System with High Resolution
Crystal Clear Sharp Images
High Quality Professional Grade Microscope
Eight Bright Field Magnification Settings: 40X-64X-100X-160X-400X-640X-1000X-1600X
Eight Phase Contrast Magnification Settings: 100X-160X-200X-320X-400X-640X-1000X-1600X
Upward Stage Stopper to Protect Slides and Objectives
Abbe Condenser with Iris Diaphragm & Swing-In Color Filter
Rack and Pinion Control for Condenser
Built-in Halogen Illumination System with Variable Brightness
Focusing Control Knobs on Both Sides
Four DIN Achromatic Objectives
Three Phase Contrast DIN Achromatic Plan Objectives
Two Sets of Eyepiece Included
Full Optical Glass Elements
Precise Ground Glass Lens
All Metal Mechanical Components
Adjustable Interpupillary Distance
Adjustable Diopters on Both Oculars
Rugged Cast Alloy Frame and Stand with Stain Resistant Enamel Finish
Spare Bulb, Fuse and Immersion Oil Included
Plan-Concave Mirror Included
Manufactured under ISO 9001 Quality Control Standard.
Excellent Five (5) Year Factory Warranty.
Phase Contrast: Simple
Nosepiece: ball bearing quadruple
Mechanical Tube Length: 6-5/16" (160mm)
Head: compensation free binocular inclined at 30 degree
Wide-Field Eyepieces: WF10X & P16X
Interpupillary Distance: 2-3/16" - 3" (55 - 75mm)
Achromatic Objectives:
4X (0.1), 10X (0.25), 40X (0.65, spring), 100X (1.25, spring, oil)
Phase Contrast Plan Objectives:
Plan PH 10X(0.25), PH 40X(0.65) & PH 100X(1.25) (160/0.17)
Stage Dimensions: 5-1/2"x 6-5/16" (140x160mm)
Stage Traveling Range: 2-3/4"x 2-0" (70x50mm)
Focusing Range: 1-3/16" (30mm)
Division of Fine Focusing: 0.0000787" (0.002mm)
Abbe Condenser: NA=1.25 with rack and pinion focusing control
Microscope Dimensions: 10" x 9" x 16"
Illumination: 6V/20W halogen lamp.
Power Supply: 110V/220V, CE certified.
Accessories: 6V/20W spare halogen bulb, 2" plan-concave mirror,
bottle of objective oil, and blue, green & yellow filters
One Binocular Microscope with Frame and Base
Four High Quality DIN Objectives, 4X, 10X, 40X and 100X
One Pair of Widefield 10X Eyepieces
One Pair of Widefield 16X Eyepieces
One Complete Phase Contrast Kit
one Dust Cove
One Power Cord
One 6V/20W Spare Halogen Bulb
Color Filters, Spare Fuses and a bottle of Sample Immersion Oil Included
User's Microscope Manual
Shipping Weight: 40 (30+10) lbs
Package: 2
A Phase Contrast and Bright Field Microscopy System
Perfect for Clinics, Vets, Doctors and Researchers
Quadruple, Reversed, Extra-Large Nosepiece with Wide, Knurled Grip for Easy Operation
30 Degree Inclined 360 Degree Swiveling Compensation-free Binocular Head
Large 3-D Double Layer Mechanical Stage with Stain Resistant Finish
Low Position Coaxial Stage Movement Control Knobs
Coaxial Coarse & Fine Focusing with CA Knob Tension Control
Fully Coated Optical System with High Resolution
Crystal Clear Sharp Images
High Quality Professional Grade Microscope
Eight Bright Field Magnification Settings: 40X-64X-100X-160X-400X-640X-1000X-1600X
Eight Phase Contrast Magnification Settings: 100X-160X-200X-320X-400X-640X-1000X-1600X
Upward Stage Stopper to Protect Slides and Objectives
Abbe Condenser with Iris Diaphragm & Swing-In Color Filter
Rack and Pinion Control for Condenser
Built-in Halogen Illumination System with Variable Brightness
Focusing Control Knobs on Both Sides
Four DIN Achromatic Objectives
Three Phase Contrast DIN Achromatic Plan Objectives
Two Sets of Eyepiece Included
Full Optical Glass Elements
Precise Ground Glass Lens
All Metal Mechanical Components
Adjustable Interpupillary Distance
Adjustable Diopters on Both Oculars
Rugged Cast Alloy Frame and Stand with Stain Resistant Enamel Finish
Spare Bulb, Fuse and Immersion Oil Included
Plan-Concave Mirror Included
Manufactured under ISO 9001 Quality Control Standard.
Excellent Five (5) Year Factory Warranty.
Phase Contrast: Simple
Nosepiece: ball bearing quadruple
Mechanical Tube Length: 6-5/16" (160mm)
Head: compensation free binocular inclined at 30 degree
Wide-Field Eyepieces: WF10X & P16X
Interpupillary Distance: 2-3/16" - 3" (55 - 75mm)
Achromatic Objectives:
4X (0.1), 10X (0.25), 40X (0.65, spring), 100X (1.25, spring, oil)
Phase Contrast Plan Objectives:
Plan PH 10X(0.25), PH 40X(0.65) & PH 100X(1.25) (160/0.17)
Stage Dimensions: 5-1/2"x 6-5/16" (140x160mm)
Stage Traveling Range: 2-3/4"x 2-0" (70x50mm)
Focusing Range: 1-3/16" (30mm)
Division of Fine Focusing: 0.0000787" (0.002mm)
Abbe Condenser: NA=1.25 with rack and pinion focusing control
Microscope Dimensions: 10" x 9" x 16"
Illumination: 6V/20W halogen lamp.
Power Supply: 110V/220V, CE certified.
Accessories: 6V/20W spare halogen bulb, 2" plan-concave mirror,
bottle of objective oil, and blue, green & yellow filters
One Binocular Microscope with Frame and Base
Four High Quality DIN Objectives, 4X, 10X, 40X and 100X
One Pair of Widefield 10X Eyepieces
One Pair of Widefield 16X Eyepieces
One Complete Phase Contrast Kit
one Dust Cove
One Power Cord
One 6V/20W Spare Halogen Bulb
Color Filters, Spare Fuses and a bottle of Sample Immersion Oil Included
User's Microscope Manual
Shipping Weight: 40 (30+10) lbs
Package: 2
![0.7X-5X Zoom 1080p 60fps 2MP Auto-focus HDMI Digital Inspection Microscope with Ring-light]()
![0.7X-5X Zoom 1080p 60fps 2MP Auto-focus HDMI Digital Inspection Microscope with Ring-light]()
![3.5X-180X Black Trinocular Stereo Zoom Microscope on Single Arm Boom Stand + 144 Direction Adjustable LED Ring Light & USB3.0 5MP Camera]()
![3.5X-180X Black Trinocular Stereo Zoom Microscope on Single Arm Boom Stand + 144 Direction Adjustable LED Ring Light & USB3.0 5MP Camera]()
![3.5X-90X Simul-Focal Stereo Zoom Microscope on Boom Stand with 144-LED Ring Light and 18MP USB3 Camera]()
![40X-2000X Trinocular Compound Darkfield Microscope with 100X Iris Objective and 1.2MP Low-noise Camera]()
![40X-2000X Trinocular Compound Darkfield Microscope with 100X Iris Objective and 1.2MP Low-noise Camera]()
![40X-2000X Trinocular Compound Darkfield Microscope with Oil Condenser and 100X Iris Objective]()
![40X-2000X Trinocular Compound Darkfield Microscope with Oil Condenser and 100X Iris Objective]()
Unsure Which Microscope?
Check Out Our Buying Tips
Confused?
Our Experts Can Help Suggest The Best Microscope For Your Needs
Featured
Accu-Scope 3000 LED Microscope
$1,122.00
$936.00
Accu-Scope 3000 Digital Microscope Package
$2,368.00
$1,977.00
AmScope Turret Phase Contrast Binocular Microscope 40X-1600X
- SKU: B600A-PCT
$1,377.99
$1,653.99
This professional binocular microscope offers turret phase contrast features. It is designed for advanced applications in clinical offices and research laboratories. This microscope comes with a 30 degree inclined 360 degree swiveling compensation free binocular head, 3-D mechanical stage and intensity-variable halogen illumination system. It offers eight phase contrast settings (100X-160X-200X-320X-400X-640X-1000X-1600X) and eight bright field magnification powers (40X-64X-100X-160X-400X-640X-1000X-1600X). The turret phase contrast kit includes a phase contrast condenser, CT lens and a set of phase contrast 10X, 20X, 40X and 100X PLAN objectives.
Features:
Specifications :
4X (0.1), 10X (0.25), 40X (0.65, spring), 100X (1.25, spring, oil)
Plan PH 10X(0.25), PH 40X(0.65) & PH 100X(1.25) (160/0.17)
bottle of objective oil, and blue, green & yellow filters
Packing List :
AmScope B600A-PCT Microscope
This professional binocular microscope offers turret phase contrast features. It is designed for advanced applications in clinical offices and research laboratories. This microscope comes with a 30 degree inclined 360 degree swiveling compensation free binocular head, 3-D mechanical stage and intensity-variable halogen illumination system. It offers eight phase contrast settings (100X-160X-200X-320X-400X-640X-1000X-1600X) and eight bright field magnification powers (40X-64X-100X-160X-400X-640X-1000X-1600X). The turret phase contrast kit includes a phase contrast condenser, CT lens and a set of phase contrast 10X, 20X, 40X and 100X PLAN objectives.
Features:
Specifications :
4X (0.1), 10X (0.25), 40X (0.65, spring), 100X (1.25, spring, oil)
Plan PH 10X(0.25), PH 40X(0.65) & PH 100X(1.25) (160/0.17)
bottle of objective oil, and blue, green & yellow filters
Packing List :
AmScope B600A-PCT Microscope
