AmScope 5.0MP CCD Fluorescent Microscope Camera
AmScope 5.0MP CCD Fluorescent Microscope Camera
AmScope 5.0MP CCD Fluorescent Microscope Camera

AmScope 5.0MP CCD Fluorescent Microscope Camera

Available: In Stock
Wishlist
  • Product SKU: MT5000-CCD
$1,373.99 $2,747.98
Request Quote

This is a brand new 5.0MP high resolution cooled CCD color digital imaging system that is designed especially for fluorescence microscopy applications. With Sony CCD chips, it features for ultra low light applications including dark field fluorescence imaging. Specially designed program allows long time exposure up to 60 minutes.

Different from other sellers' models, this new microscope imaging system comes with a standalone design that allows independent operation for high-definition digital imaging at a hardware resolution of 5.0 megapixel effective pixels without using any image capture card, optimizes real-time acquisition, and fine-tunes exposure and white balance settings to achieve the best balance between resolution and contrast.

In addition, the multi-functional software allows you to preview live images, record videos, capture still pictures, edit captures, or save them in BMP, TIFF, JPG, PICT, PTL and other formats very easily, as well as conduct length, angle, area, and other measurements. This product is very simple to use. It is ideal for medical, educational, and engineering uses. It comes with a one-year full-coverage warranty and a life-time of free software upgrades. We have no doubt you will be impressed by the superb resolution and quality this microscope camera offers you.

Specifications:

  • Image Sensor: 2/3" Sony Color CCD, Model ICX282AQ
  • CCD Scan Mode: Interline
  • Pixel Size: 3.4micron x 3.4micron
  • Resolution: 2580(H) x 1944(V) Pixels
  • G Sensitivity: 280mV
  • Filter: RGB Bayer Pattern
  • Port: Standard C-Mount
  • Frame Rate: 3 fps @ 2580x1944 pixels; 10 fps @ 1280x932 pixels
  • Low-speed Readout: Yes
  • A/D conversion: 12 bit
  • Peltier Cooled: -30??°C below ambient
  • Power Supply: 3.5V exterior power supply
  • Exposure Control: automatic/manual
  • Exposure Time: 0.1 - 60 minutes
  • Angle Light Control: Yes
  • White Balance: automatic/manual
  • Parameter: image size, bright, gain, exposure, RGB
  • Data interface: USB2.0/480Mb/s
  • Operational Temperature: 0 - 60 (C)
  • Operational Humidity: 45 - 85%
  • Storage Temperature: -20-70??°C
  • Power Supply: Via USB 2.0 connector
  • USB Cable: 98" (2.5m)
  • Dimension: 2.5" x 3-3/8" x 1-7/16" (130 x 111 x 54 mm)
  • Net Weight: 2 lbs (1 kg)
  • Shipping Weight: 5 lbs
  •

    Packing List:

  • One 5.0MP Fluorescence Microscopy Color Digital Camera
  • One 8' (2.5m) USB Cable
  • One Peltier Cooled Cable
  • One Peltier Cooled Power Supply
  • One CD with Software, Driver and User's Instructions
  • One Aluminum Case
  • One CD with Software, Driver and User's Instructions
  • Certificate

  • AmScope MT5000-CCD
