Name: AmScope 3.5X-90X Jewelry Gem Stereo Microscope + Dual Halogen + 9MP USB Camera
Brand: AmScope
SKU: SM-2TZ-DK-9M
Price: 938.99 USD
Availability: InStock

Description

This first-class 3.5X-90X trinocular jewelry/gem stereo zoom microscope comes with a 9MP USB digital camera. It incorporates all the most excellent features of a high quality laboratory instrument and contemporary digital image technology. Designed to meet the demands of modern gemology microscopy, this microscope exceeds all expectations. It provides super widefield optics and comes with a gem clamp and darkfield condenser with iris diaphragm.

This microscope offers high resolution and good depth within a broad field of view. With super widefield optics, it gives crystal clear images. It provides 2-1/2" (65mm) super widefield, 26:1 large zoom range and 8" (200mm) long working distance. The 45 degree inclined binocular and high-eyepoint design ensures an easy observation for all users including eyeglass wearers. The versatile illumination system with the microscope provides both incident (top) lighting and transmitted (bottom) lighting. The top lighting shining down onto objects is used for the observation of surface details and fine structures of jewels or gemstones. The transmitted illumination through the condenser is for the examination of inside quality of diamonds.

The digital camera captures still images and video, and allows you to view a live stream on your PC. With software available for Windows, Mac, and Linux, it's a multi-platform imaging solution. The included Windows software offers image-development and measurement tools, as well as advanced compositing features such as image-stitching and extended-depth-of-focus. Independent preview and capture resolutions allow you to view high-speed video while capturing high-definition images. For Mac and Linux, there is a lite version with limited processing features. This microscope is an ideal instrument for gemologists, jewelry dealers and collectors.

Features :

A great jewelry/gem stereo microscope

A brightfield and darkfield microscopy system for jewelry/gem applications

Darkfield condenser with iris included

Jewelry/gem clamp included

3.5X-90X large zoom range continuous magnification

26:1 extremely large zoom range

8" (200mm) large working distance

45 degree inclined trinocular head with SUPER widefield eyepieces

High-eyepoint design for easy observation for all users including eyeglass wearers

23mm upright tube for photo or video accessories

30mm SUPER widefield eyepieces included

High resolution with great flatness and contrast

Sharp stereo erect images over a SUPER widefield of view

Crystal clear original true color images

Both ocular-tubes with adjustable diopter

Metal pillar stand finished with stain resistant enamel

Accurate alignment ensuring a fatigue-free long time viewing

Full optical glass elements

Precise ground glass lens

All metal mechanical components

Adjustable interpupillary distance

Rubber eye-guards included

Built-in Epi-illuminating and transmitted lighting system with adjustable intensity

CE approval electric apparatus

Manufactured Under ISO 9001 Quality Control Standard

Excellent Five (5) Year Factory Warranty

Specifications :

Head: 45 degree inclined 360 degree swiveling trinocular

Eyepiece: 30mm super wide field high-eyepoint WF10X/20

Objective: 0.7X-4.5X

Barlow Lens: 0.5X and 2.0X

Zoom Range: 26:1

Diopter Adjustment: +/-5dp

Interpupillary Distance: 2-3/16" - 2-15/16" (55-75mm)

Working Distance: 8" (200mm)

Field of View: 2-1/2" (65mm)

Frosted Glass Plate: 3-3/4" (95mm) in diameter

White/Black Plastic Plate: 3-3/4" (95mm) in diameter

Incident (Top) Illumination: 12V/15W halogen bulb

Transmitted (Bottom) Illumination: 12V/15W halogen bulb

Power Supply: 110V/60Hz (220V/50Hz version available)

Accessories: dust cover, eye-guards and clips

Shipping Weight: 20 lbs

Camera Specifications:

Sensor: Aptina

Sensor Type: CMOS

Sensor Size: 5.825x4.369mm

Pixel Size: 1.67

Resolution: 9.0MP

Frame Rate: 11.9@3488x2616, 8@1744x1308, 27@872x654

Sensitivity: 0.31 V/lux-sec

Compatibility: Windows (32/64 bit) XP/Vista/7/8/10, Mac OSX, Linux

Software Specifications:

OS Requirements: Windows (32/64 bit) XP/Vista/7/8/10, Mac OS 10.8+, Linux kernel 3.13+

Hardware Requirements: Intel Core2 2.8GHz or comparable processor, 2GB RAM, USB2.0 port

Packing List:

One Trinocular Stereo Zoom Head

One Pair of High-Eyepoint 10X Eyepieces

One 0.5X Barlow Lens

One 2X Barlow Lens

One Darkfield condenser

One Jewelry Tweezer

One Pillar Base with Bottom Light

One Focusing Rack

One Frosted Round Glass Plate

One White/Black Round Working Plate

One Power Cord

One Pair of Clips and One Pair of Eye-guards

One Spare Bulb

One Dust Cover

User's Microscope Manual

One 9MP Digital Camera with Software/Driver and Reduction Lens

Step-by-step Camera User's Instructions

AmScope SM-2TZ-DK-9M Microscope
