AmScope 3.5X-90X Jewelry Gem Stereo Microscope + Dual Halogen + 10MP USB Camera

AmScope 3.5X-90X Jewelry Gem Stereo Microscope + Dual Halogen + 10MP USB Camera

This first-class 3.5X-90X trinocular jewelry/gem stereo zoom microscope comes with a 10MP USB digital camera. It incorporates all the most excellent features of a high...

$725.00
Request Quote
Add to wishlist

This first-class 3.5X-90X trinocular jewelry/gem stereo zoom microscope comes with a 10MP USB digital camera. It incorporates all the most excellent features of a high quality laboratory instrument and contemporary digital image technology. Designed to meet the demands of modern gemology microscopy, this microscope exceeds all expectations. It provides super widefield optics and comes with a gem clamp and darkfield condenser with iris diaphragm.

This microscope offers high resolution and good depth within a broad field of view. With super widefield optics, it gives crystal clear images. It provides 2-1/2" (65mm) super widefield, 26:1 large zoom range and 8" (200mm) long working distance. The 45 degree inclined binocular and high-eyepoint design ensures an easy observation for all users including eyeglass wearers. The versatile illumination system with the microscope provides both incident (top) lighting and transmitted (bottom) lighting. The top lighting shining down onto objects is used for the observation of surface details and fine structures of jewels or gemstones. The transmitted illumination through the condenser is for the examination of inside quality of diamonds.

The digital camera captures still images and video, and allows you to view a live stream on your PC. With software available for Windows, Mac, and Linux, it's a multi-platform imaging solution. The included Windows software offers image-development and measurement tools, as well as advanced compositing features such as image-stitching and extended-depth-of-focus. Independent preview and capture resolutions allow you to view high-speed video while capturing high-definition images. For Mac and Linux, there is a lite version with limited processing features. This microscope is an ideal instrument for gemologists, jewelry dealers and collectors.

Features :

  • A great jewelry/gem stereo microscope with color USB digital camera
  • A brightfield and darkfield microscopy system for jewelry/gem applications
  • Darkfield condenser with iris included
  • Jewelry/gem clamp included
  • 3.5X-90X large zoom range continuous magnification
  • 26:1 extremely large zoom range
  • 8" (200mm) large working distance
  • 45 degree inclined trinocular head with SUPER widefield eyepieces
  • High-eyepoint design for easy observation for all users including eyeglass wearers
  • 23mm upright tube for photo or video accessories
  • 30mm SUPER widefield eyepieces included
  • High resolution with great flatness and contrast
  • Sharp stereo erect images over a SUPER widefield of view
  • Crystal clear original true color images
  • Both ocular-tubes with adjustable diopter
  • Metal pillar stand finished with stain resistant enamel
  • Accurate alignment ensuring a fatigue-free long time viewing
  • Full optical glass elements
  • Precise ground glass lens
  • All metal mechanical components
  • Adjustable interpupillary distance
  • Rubber eye-guards included
  • Built-in Epi-illuminating and transmitted lighting system with adjustable intensity
  • CE approval electric apparatus
  • Manufactured Under ISO 9001 Quality Control Standard
  • Excellent Five (5) Year Factory Warranty
  •

    Specifications :

  • Head: 45 degree inclined 360 degree swiveling trinocular
  • Eyepiece: 30mm super wide field high-eyepoint WF10X/20
  • Objective: 0.7X-4.5X
  • Barlow Lens: 0.5X and 2.0X
  • Zoom Range: 26:1
  • Diopter Adjustment: +/-5dp
  • Interpupillary Distance: 2-3/16" - 2-15/16" (55-75mm)
  • Working Distance: 8" (200mm)
  • Field of View: 2-1/2" (65mm)
  • Frosted Glass Plate: 3-3/4" (95mm) in diameter
  • White/Black Plastic Plate: 3-3/4" (95mm) in diameter
  • Incident (Top) Illumination: 12V/15W halogen bulb
  • Transmitted (Bottom) Illumination: 12V/15W halogen bulb
  • Power Supply: 110V/60Hz (220V/50Hz version available)
  • Accessories: dust cover, eye-guards and clips
  • Shipping Weight: 20 lbs
  •

    Camera Specifications:

  • Sensor: Aptina MT9J003
  • Sensor Type: CMOS
  • Sensor Size: 6.44x4.616mm
  • Pixel Size: 1.67
  • Resolution: 10.0MP
  • Frame Rate: 1.9@3584x2748, 8@1792x1374, 27@896x684
  • Sensitivity: 0.31 V/lux-sec
  • Compatibility: Windows (32/64 bit) XP/Vista/7/8/10, Mac OSX, Linux
  •

    Software Specifications:

  • OS Requirements: Windows (32/64 bit) XP/Vista/7/8/10, Mac OS 10.8+, Linux kernel 3.13+
  • Hardware Requirements: Intel Core2 2.8GHz or comparable processor, 2GB RAM, USB2.0 port
  •

    Packing List:
  • One Trinocular Stereo Zoom Head
  • One Pair of High-Eyepoint 10X Eyepieces
  • One 0.5X Barlow Lens
  • One 2X Barlow Lens
  • One Darkfield condenser
  • One Jewelry Tweezer
  • One Pillar Base with Bottom Light
  • One Focusing Rack
  • One Frosted Round Glass Plate
  • One White/Black Round Working Plate
  • One Power Cord
  • One Pair of Clips and One Pair of Eye-guards
  • One Spare Bulb
  • One Dust Cover
  • User's Microscope Manual
  • One 10MP Digital Camera with Reduction Lens
  • Two Mounting Adapters
  • One USB Cable
  • One CD with Driver, Software and User's Instructions

  • AmScope SM-2TZ-DK-10M Microscope
