AmScope 10X-45X Track-mounted Stereo Zoom Microscope with Dual Lighting

AmScope 10X-45X Track-mounted Stereo Zoom Microscope with Dual Lighting

The NM-2BR is a track-mounted stereo microscopy system with reflected and transmitted lighting. The track-stand maintains consistent head-position, and has two collar-mounting positions. The microscope provides 1X...

$293.99
Request Quote
Add to wishlist

The NM-2BR is a track-mounted stereo microscopy system with reflected and transmitted lighting. The track-stand maintains consistent head-position, and has two collar-mounting positions. The microscope provides 1X to 4.5X zoom-objective magnification, with a 10X to 45X magnification when used with the 10X eyepieces. With 120mm working-distance, there is ample room for hands-on applications, such as soldering and dissection. Additional eyepieces and Barlow lenses can be used to extend the magnification range. A collar-mounted 3W LED provides incident illumination, while a sub-stage 1W LED provides transmitted illumination.

Specifications:



  • Head Type: binocular stereo
  • Interpupillary Adjustment Range: 55-75mm
  • Objective: 1X-4.5X zoom
  • Working Distance: 4.725in (120mm)
  • Eyepieces: 10X FN22 Plan
  • Focus Control: coarse
  • Track Height: 10.625in (270mm)
  • Track Travel Range: 4.33in (110mm)
  • Reflected Light-source: 3W LED
  • Transmitted Light-source: 1W LED
  •



    Packing List:



  • One Binocular Stereo Zoom Head
  • One Pair of 10X Eyepieces
  • One Pair of Eye-guards
  • One LED Top-Light
  • One Track Stand with LED Illumination
  • One Pair of Stage-Clips
  • One Dust Cover
  • One Power Cord
  • NM-2BR

  •
