Accu-Scope EXC-400 Dermatology MOHS Surgery Microscope

Recently viewed

Accu-Scope EXC-400 Dermatology MOHS Surgery Microscope
Accu-Scope EXC-400 Dermatology MOHS Surgery Microscope
Accu-Scope EXC-400 Dermatology MOHS Surgery Microscope

Accu-Scope EXC-400 Dermatology MOHS Surgery Microscope

  • SKU: EXC-400-DERM-T-20
$3,081.00 $3,691.00
  • Trinocular or Ergo Binocular Head
  • 2x Objective Included
  • Ceramic Stage
  • LED Kohler Illumination
  • 5 Year Mechanical & 1 Year Electrical Warranty
Head
Objectives
Quote Request

This pathology grade microscope from Accu-Scope is ergonomically designed, and suitable to withstand heavy use, while providing high resolution images. A trinocular head is standard, and for added ergonomics you can upgrade to a tilting binocular head. The 10x focusing eyepieces provide a 22mm field of view and come with roll down eyeguards for added viewing comfort. A reversed quintuple nosepiece and can accept up to five objectives and has a slot for to insert an analyzer. The EXC-400 offers optical brilliance coming standard with Infinity Plan Achromatic 2x, 4x, 10x, 20, you can add an optional 40x objective. The rackless XY-mechanical stage is ergonomically positioned with tension adjustment to effortlessly move your specimen with precision. You can remove the slide holder for freehand use. The low-position of the XY-stage stalk, and coarse / fine focus knobs make using this microscope easy and comfortable to use. A 1.25 N.A. achromatic flip top condenser is supplied for use with the 2x objective lens. The LED variable illuminator provides over 20,000 hours of use and has a field iris diaphragm for koehler illumination. The Accu-Scope EXC-400 clinical microscope can upgraded to come with a high speed camera, or dual viewing attachment.



Specifications
Head:

Trinocular viewing head, inclined 30°, rotatable 360°, 50/50 light split

 Or

Ergonomic Tilting Head 5° to 35°

Eyepieces: WF10x/22mm focusing eyepieces with eyeguards
Nosepiece: Reversed quintuple nosepiece, with slot
Objectives: Infinity Plan Achromat 2x, 4x, 10x, 20x - Optional 40x Objectives
Condenser: N.A. 1.25 Swing Out Achromatic with iris diaphragm
Stage: Rackless w/ adjustable tension
Focusing: Coaxial low position ergonomic coarse & fine focus
Illumination: 3 Watt Variable LED w/ field iris for koehler illumination
Accessories: Dust cover, power cord, manual
Warranty: 5 Year Mechanical & Electrical

This pathology grade microscope from Accu-Scope is ergonomically designed, and suitable to withstand heavy use, while providing high resolution images. A trinocular head is standard, and for added ergonomics you can upgrade to a tilting binocular head. The 10x focusing eyepieces provide a 22mm field of view and come with roll down eyeguards for added viewing comfort. A reversed quintuple nosepiece and can accept up to five objectives and has a slot for to insert an analyzer. The EXC-400 offers optical brilliance coming standard with Infinity Plan Achromatic 2x, 4x, 10x, 20, you can add an optional 40x objective. The rackless XY-mechanical stage is ergonomically positioned with tension adjustment to effortlessly move your specimen with precision. You can remove the slide holder for freehand use. The low-position of the XY-stage stalk, and coarse / fine focus knobs make using this microscope easy and comfortable to use. A 1.25 N.A. achromatic flip top condenser is supplied for use with the 2x objective lens. The LED variable illuminator provides over 20,000 hours of use and has a field iris diaphragm for koehler illumination. The Accu-Scope EXC-400 clinical microscope can upgraded to come with a high speed camera, or dual viewing attachment.



Specifications
Head:

Trinocular viewing head, inclined 30°, rotatable 360°, 50/50 light split

 Or

Ergonomic Tilting Head 5° to 35°

Eyepieces: WF10x/22mm focusing eyepieces with eyeguards
Nosepiece: Reversed quintuple nosepiece, with slot
Objectives: Infinity Plan Achromat 2x, 4x, 10x, 20x - Optional 40x Objectives
Condenser: N.A. 1.25 Swing Out Achromatic with iris diaphragm
Stage: Rackless w/ adjustable tension
Focusing: Coaxial low position ergonomic coarse & fine focus
Illumination: 3 Watt Variable LED w/ field iris for koehler illumination
Accessories: Dust cover, power cord, manual
Warranty: 5 Year Mechanical & Electrical
