  • SKU: 3001-LED-HEMA-HD
$2,582.00 $2,935.00
  • Choose With or Without Screen
  • Infinity Plan Achromat 10x, 40x, 50x Oil, 100x Oil Objectives
  • All Metal Gears
  • LED Illumination
  • 5 Year Mechanical & Electrical Warranty
Camera
Quote Request

The Accu-Scope 3000-LED digital microscope configured for hematology applications is a high quality laboratory grade microscope. The trinocular viewing head comes with the c-mount adapter for the camera. The 10x eyepieces provide a large 20mm field of view, allowing you to view more of your specimen. A set of infinity plan achromat 10x, 40x, 50x Oil, and 100x Oil offer sharp high resolution images. The mechanical XY stage provides smooth and precise movements. A 1.25 N.A. condenser is fully focusable and the 3 watt LED illumination system offers variable intensity. This reliable microscope has all metal internal gears with a solid build and feel.

You can choose to have an 11.6" retina display screen above the eyepieces to view, capture images / videos to a removable SD card, or replay images / videos. In addition you can also output directly to a PC. If you do not select the screen, you can still output HDMI to your own screen off to the side, or USB to a computer. The screen serves as an all-in-one streamlined solution. The included camera is a powerful tool that can output HDMI to any monitor or USB to a computer. In HDMI mode on-board software pops up on your screen allowing you to control the camera with the included mouse. The camera can also output to a PC for use with the free feature rich software -  image / video capture, measurements, extended depth of focus, annotations, stitching, and more!

      Specifications
      Head: Trinocular, 30⁰ inclined and rotatable 360⁰ & C-Mount
      Eyepieces: HWF Plan 10x eyepiece, 20mm field of view with built-in diopter adjustment; a pointer is standard in one eyepiece
      Nosepiece: Reversed, quadruple
      Objectives: Infinity Plan Achromat 10x, 40xR*, 50x Oil R* 100x Oil R* (*spring-loaded)
      Condenser: N.A. 1.25 Abbe condenser
      Stage: Mechanical stage, 140 x 132mm with X-Y movement range of 76 x 50mm
      Illumination:

      3 watt LED with variable intensity control

      Universal power supply 110-220v

      Focusing: Coaxial focusing system with an adjustable tension control and upper limit stop to prevent accidental damage to slides; all metal gears, brass fine focus gear
      Accessories: Dust cover, immersion oil & instruction manual included
      Warranty: 5 Year Mechanical & Electrical


       Camera Specifications:
      Optional Screen: 11.6" Retina Display Screen
      Resolution (Live): 1920 x 1080 - Captured  5 M.P.
      Sensor:

      1/2.5" (0.5x C-mount recommended); APTINA MT9P031

      Frame Rate:

      HDMI (30fps); USB 2.0 (15fps)

      Image Capture: High Speed SD Card (4GB)
      Video Capture: HDMI: 1080p, 30fps to SD Card
      USB 2.0: 1080p, 15fps to PC or Mac
      Exposure Time: 0.001 sec - 10.0 sec
      White Balance: Auto
      Settings: Gain, Gamma, Saturation, Contraction
      Built-in Software: Cloud 1.0
      PC Imaging Software: CaptaVision Imaging Software (for PC only; Mac OS not supported)
      Advanced Camera Controls: live/still image measurement and annotation, flat field correction; extended depth of focus (focus stacking); image stitching; HDR (High Dynamic Range) function
      Image Types: JPEG, BMP, TIFF and RAW
      Output Modes: Mode 1: USB 2.0 / Mode 2: HDMI
      System Compatibility: Windows XP, Vista 7 and 8, and 10 (32 or 64-bit)
      Mac OS X (for image transfer to Mac OS X only)
      System Requirements: Intel processor (Core 2 Duo or higher); 2GB memory or more; USB 2.0 Hi-Speed port
      Power Supply: DC12V/1A
      Warranty: 1 year
