40X-2000X Trinocular Compound Darkfield Microscope with Oil Condenser and 100X Iris Objective
40X-2000X Trinocular Compound Darkfield Microscope with Oil Condenser and 100X Iris Objective

40X-2000X Trinocular Compound Darkfield Microscope with Oil Condenser and 100X Iris Objective

Available: In Stock
Wishlist
$750.99
Request Quote

This professional trinocular compound microscope provides both darkfield and brightfield features. It boasts three unique features no other microscope dealer can claim, designed for professional applications in clinical offices and research laboratories. Different from most other microscopes on the market, the T490B is remarkable because it features 1) simultaneous viewing through the photo port and eyepieces, 2) an adjustable parfocal trinocular port, and 3) a detachable C-Mount located on the 23mm photo port. T490B's adjustable trinocular port creates a parfocal optical system by allowing the image system attached to the photo port and the image in the eyepieces to be in focus at the same time. Traditional microscopes on the market allow you to see through either the trinocular port or eyepieces, forcing you to switch between the port and eyepieces. Because their trinocular port is not designed to be par-focal with the microscope optical system, you have to conduct re-focusing after each "switch". The T490B, however, has simultaneous viewing and parfocal trinocular port so that these "switch" and "re-focusing" are no longer necessary. Especially handy for teaching demonstrations, clinical examinations and laboratory applications, these features allow your students or colleagues to view crystal clear images simultaneously while you work through the eyepieces. In addition, the T490B's industry standard 23mm photo port can be converted into a C-Mount port by putting on the free C-mount adapter included, allowing you to attach most of microscope digital cameras and video systems on the market. This versatile microscope is also capable of being upgraded with various accessories and attachments for additional functions. The T490B also includes a 30° inclined 360° swiveling compensation-free trinocular head, a 3-D mechanical stage, and an intensity-variable halogen illumination system.

Features :

  • A Great Affordable Brightfield and Darkfield Microscopy System
  • Boasting Three Unique Features No Other Microscope Dealer on eBay Can Claim!
  • Simultaneous Viewing Through the Photo Port and Eyepieces
  • Adjustable Parfocal Trinocular Port
  • Industry Standard 23mm Photo Port and C-mount Port
  • 30° Inclined 360° Swiveling Compensation Free Trinocular Head
  • Photo/Video Capability with Adjustable 23mm Photo Mount for Parfocal Image System
  • Large 3-D Double Layer Mechanical Stage with Stain Resistant Finish
  • Low Position Coaxial Stage Movement Control Knobs
  • Coaxial Coarse Fine Focusing with CA Knob Tension Control
  • Fully Coated Optical System with High Resolution
  • Crystal Clear Sharp Images
  • High Quality Professional Grade Microscope
  • Perfect for Clinics, Vets, Doctors and Medical School Students
  • Eight Settings of Magnification: 40X-80X-100X-200X-400X-800X-1000X-2000X
  • Upward Stage Stopper to Protect Slides and Objectives
  • Abbe Condenser with Iris Diaphragm Filters
  • Rack and Pinion Adjustment for Condensers
  • Darkfield Oil Condenser
  • Built-in Halogen Illumination System with Variable Intensity
  • Focusing Control Knobs on Both Sides
  • Four standard DIN Achromatic Objectives Included, plus one plan objective with iris for darkfield
  • Two Sets of Eyepiece Included
  • Full Optical Glass Elements
  • Precise Ground Glass Lenses
  • All Metal Mechanical Parts
  • Adjustable Interpupillary Distance
  • Adjustable Diopters on Both Oculars
  • Full Solid Metal Frame Construction with Stain Resistant Enamel Finish
  • Spare Bulb, Fuse and Immersion Oil Included
  • Manufactured under Restrict ISO 9001 Quality Control Standards
  • Excellent Five (5) Year Factory Warranty



Specifications :

  • Nosepiece: quadruple
  • Mechanical Tube Length: 6-5/16" (160mm)
  • Head: 360° swiveling compensation free trinocular head inclined at 30°
  • Eyepieces: WF10X and WF20X
  • Achromatic Objectives: 4X, 10X, 40X (spring), 100X (spring, oil)
  • Plan Achromatic Objective: 100X (spring, oil, iris)
  • Stage Dimensions: 5-1/2"x 5-1/2" (140x140mm)
  • Stage Traveling Range: 2-15/16"x 1-3/4" (75x45mm)
  • Focusing Range: 1-3/16" (30mm)
  • Division of Fine Focusing: 0.0000787" (0.002mm)
  • Abbe Condenser: NA=1.25 with rack and pinion focusing control
  • Illumination: 6V/20W halogen bulb
  • Power Supply: 110V (220V version available), CE certified
  • Accessories: 6V/20W spare halogen bulb, immersion oil, blue, green yellow filters
  • Microscope Dimensions: 12" x 9" x 16"



Packing List :

  • One Trinocular Compensation-Free Head
  • One 23mm Adjustable Photo Port with C-Mount Adapter
  • One Microscope Body with Frame, Base and Halogen Illumination System
  • Four High Quality DIN Objectives, 4X, 10X, 40X and 100X
  • One DIN 100X oil-immersion objective with iris
  • Two Pairs of Widefield Eyepieces, WF10X and WF20X
  • One Oil Darkfield Condenser
  • Three Color Filters
  • One 6V/20W Spare Halogen Bulb
  • One Dust Cover
  • One Power Cord
  • Spare Fuse
  • Immersion Oil
  • User's Manual Download
  • Shipping Weight: 20 lbs
